Choosing a Magnetic Manipulator Arm is a strategic decision based on the material properties of your workpieces and the specific requirements of your production environment. While vacuum and mechanical grippers are popular, they have physical limitations that magnets easily overcome.
Here is a guide on when you should choose a magnetic solution:
1. When the Material is Perforated or Irregular
This is the most common reason to choose magnets over vacuum systems.
The Problem: Vacuum grippers require a “seal.” If you are lifting a laser-cut part with holes, a mesh, or a grate, the air leaks out and the part drops.
The Solution: Magnetic force ignores holes. As long as there is enough metal surface for the magnetic flux to flow, the arm will hold the part securely.
2. When You Only Have Access to One Surface
If your parts are stacked tightly or stored in a way where you cannot get “under” or “around” them, mechanical grippers won’t work.
The Scenario: Picking a single heavy steel plate from a tall stack (destacking).
The Advantage: A magnetic arm can pick from the top surface only. There is no need for “finger room” between parts, allowing for much denser storage and tighter packing.
3. When Dealing with Oily, Dirty, or Scale-Covered Parts
In metal fabrication (especially stamping and hot-rolling), parts are often covered in industrial lubricants, rust, or mill scale.
Vacuum Failure: Oil destroys rubber vacuum cups and causes them to slip.
Mechanical Failure: Dirt can jam delicate mechanical linkages.
Magnetic Success: Magnets are solid blocks of metal. They are unaffected by oils and can “reach through” thin layers of dirt or paint to grab the metal underneath.
4. When Speed of Engagement is Critical
In high-speed “Pick and Place” operations, every millisecond counts.
The Comparison: Vacuum systems take time to “pump down” to reach a safe holding pressure. Mechanical grippers take time to physically move their fingers.
The Magnetic Edge: An Electro-Permanent Magnet (EPM) can be switched on or off with a millisecond electrical pulse. The grip is instantaneous the moment the magnet touches the metal.
